Weber 32/36 DGEV DGV Carburetor for Mazda B2200 1987-1993 & B2000 Pickup 20R 22R

Product Description
Application: for 1969-1972 Datsun Pickup L16 (1600cc) PL521 also fits Datsun 510 1973-1974 Datsun Pickup L18 (1800cc) PL620 also fits 510, 610, and 710 1975-1980 Datsun Pickup L20 (2000cc) PL620 also fits 510, 610, and 710 Nissan Sentra 720 Pulasar 2.0 1.8 1980-1983

Application: Carburetor replace for 1972-1990 CJ5, CJ7, CJ8, Wrangler Cherokee with a 258Ci W/ 2BBL Carter BBD Carb 1986-1987 Mazda B2000 2.0L 1987-1993 Mazda B2200 2.2L

Note: Please clean up the oil channels and air filters as well as use the clean fuel before installing the carburetors

Replace Part Number:
Weber 32/36 DGEV DGV DGAV
22680033B, 22680.033B
99004.300, 99004300
99005.068, 99005068
99217.332S, 99217332S

Application:
For Toyota Pickup Celica Corona 20R and 22R engines
1969-1972 Datsun Pickup L16 (1600cc) PL521 also fits Datsun 510
1973-1974 Datsun Pickup L18 (1800cc) PL620 also fits 510, 610, and 710
1975-1980 Datsun Pickup L20 (2000cc) PL620 also fits 510, 610, and 710
1982- 1978 Datsun 200SX 2.2L
1981-1982 Nissan Pickup Z20 (2000cc) PL720
1981-1983 Nissan Pickup Z22 (2200cc) PL720
1980-1981 Nissan 200SX

Nissan Sentra 1.5L 1.6L 1986
Nissan 720 2.0L 2.2L 1984
Nissan Pulsar 1.6L 1983
1972-1990 CJ5, CJ7, CJ8, Wrangler Cherokee with a 258Ci W/ 2BBL Carter BBD Carb
1986-1987 Mazda B2000 2.0L
1987-1993 Mazda B2200 2.2L
( Please double check the fitment before making an order. )

Specifications:
primary Venturi: ??26mm
Secondary Venturi;??10.5mm
Primary Auxiliary Venturi; ??27mm
Secondary Auxiliary Venturi;??10.5mm
Primary Main Jet;1.4mm
Secondary Main Jet; 1.4mm
Primary Air Corrector Jet;1.7mm
Secondary Air Corrector Jet :1.6mm
Primary Emulsion Tube; F50
Secondary Emulsion Tube; F50
Primary idle Jet;0.6mm
Secondary Idle Jet; 0.5mm
Pump Jet;??0.5mm
Needle Valve; 2.0mm
Float Measurement :47mm
