Weatherproof 8 Rear Front View Car Parking Sensors LCD Display Monitor -3 Colors

Item Description:

Function: Rear&Front View Car Parking Sensors

Main Feature:
– With 8 car parking sensor, protecting your vehicles and cars omnibearing
– With a display monitor, Support real time response and detailed reversing information displaying on the LCD display screen
– Easy to install, compatible with any vehicle
– Support weatherproof, can works in the rain and snows
– System automatically activates when reverse gear is engaged
– Set-up alarm, Support beep alert or via the color of the display screen
– Dual CPU system
– With intelligent anti-interference analysis
– With power protection function for wrong connection

8 Parking Sensor:
– 2 for rear-left, 2 for rear-right
– 2 for front- left, 2 for front-right

Display Screen: 1.8″ screen

Alert Type: Beep alert

Alert Distance:
– Rear sensor: 0.3m ~ 1.5m
– Front sensor: 0.3m ~ 0.8m

Display Distance:
– Rear sensor: 0.3m ~ 2.0m
– Front sensor: 0.3m ~ 0.8m

Alarm Volume: / = 80dB

Operation Voltage: 10V ~ 16V

Power Consumption: < 6W

Operation Temperature: -40 ~ 80 Degrees Celsius

Sensor Installation Height: 50cm ~ 70cm

3 Optional Colors of Sensor:Black as default (We also have Gray / Silver
in stock, if need you can leave us an ebay note to choose a specific color other than black)

Dimensions:
– Front sensor cable length: 6 meters
– Rear Sensor cable length: 2.5 meters
– Sensor hole diameter: 22mm
– Display Monitor: 75mm x 54mm x 22mm
– System Box: 156mm x 88mm x 24mm

About the power cable connection it is as below:
– Yellow: Car Reverse Brake Light “+”
– Blue: Car Feel Brake Light”+”
– Black: GND
– Red: ACC Power “+”

This product work like this, when you parking your car ahead:
– Press on the brake, the front parking sensor start to wrok
– If there is no barrier or road block, the sensor is at the status of sleeping. The display will not start to work avoided the affect to dri
