Turbocharger Turbo for Navistar DT466 DT466E DT466P 1825632C93 GT3782

Our Advantage:
Turbine housing uses cast iron withstand temperatures up to 700
Steel Turbine Wheel made from the special K418 alloy to achieve high oxidation resistance and stability under high temperatures up to 900
Cast aluminium blades with good gas tightness and corrosion resistance
The volute is made of nodular cast iron, which can withstand 700 degrees high temperature, and its tensile strength is as high as 450MPa.
100% BALANCING TEST:
This Turbocharger youWill receive has been balanced using the VSR machine technology.
Supercharger installation instructions:
1. Change engine oil
2. Replace air filter and oil filter
3. Clean the oil supply and oil outlet pipes to ensure that there is no damage. The oil hangs on the wall of the oil pipe and the oil pipe flow channel becomes narrow to increase the oil pressure.
4. Check the intake and exhaust pipes to ensure there is no obstruction or interference
5. Make sure the screws and clamps are tightened and there are no air leaks.
6. When installing the oil inlet and outlet holes, sealant cannot be used, only gaskets can be used.
Item Specifics
Manufacturer Part Number : LA10700101TE
Type : Turbo Charger
Model : GT3782
Warranty : 1 Year
Placement on Vehicle : Front
Custom Bundle : Yes
Fitment Type : Direct Replacement
Interchange Part Number : 179079,1825632091,1825632092,1825632C91,1825632C92
Other Part Number : 1825632C93,1825632RX1,1826344C91,1826344C92,751363-5002S
Superseded Part Number : 1826344C93,1826344RX1,1826588C91,1826588C92,1826588C93,1826344092
Country/Region of Manufacture : China
Package Contents : As the picture shows
Modified Item : NO
OE Spec or Performance/Custom : OE Spec
Non-Domestic Product : No
Turbo Model : GT3782
Engine Manufacturer : Navistar
Engine : DT466, I530E
Fuel : Diesel
Displacement : 7.6L, 7600 ccm, 6 Cyl.
KW : 250 HP
Angle (compressor housing) : 220o
Angle (turbine housing) : 270o
Feature : ESCP
