SPDT 3P 3 Position On-Off-On Toggle Wiring Boat Rocker Switch Black AC 125V/12A 250V/10A

??Wide Application??Universal for Electromagnetic furnace, Water dispenser, buses, boats, marine, trailers??kitchen appliance etc.
??DIY As You Like??Black Boat Rocker Switch, 3 terminals ON/OFF/ON switch, , longer life for use.
??Product Basic Parameters??AC 12A/125V 10A/250V.Overall Size: 21 x 15 x 25mm (L*W*H) Mounting Size: 20 x 13mm (L*W)
??Attention??Select the appropriate soldering iron to speed up the soldering. It is recommended to use 20W soldering iron to complete the soldering within 3 seconds. The flux must be in proper amount. When soldering, try to turn the switch pin down.
??Parcel contains??1x Rocker Switch Easy to install and durable.With our strict quality control system, we test each item and ensure in good condition before we ship.
AC 250V Current rerating for different loads
Inductive Load: 3.5A??Lamp Load: 1.8A??Motor Load: 2A??Capactive Load: 1.8A
AC125V Current rerating for different loads
Inductive Load: 4.2??ALamp Load: 2.16A??Motor Load: 2.4A??Capactive Load: 2.16A
Very Important Notice:Ratings on the switch label are only for Purely Resistive AC load, for other types of loads please refer to the ratings above.DC load Current ratings are much lower than AC load,if you need to use this switch with more than 0.5A DC load, ask us for compatibility at first.
Household Appliance Control
DIY Power Control
Industry Power Control
Auto Boat Control
Control Type
SPST Control Type
Single Pole Single Throw (SPST) is a control type that the switch has only a single input terminal to only one output terminal. This switch serves in circuits as on-off switches.
SPDT Control Type
Single Pole Double Throw (SPDT) is a control type that the switch has only a single input terminal to two output terminal. This switch serves in circuits as on-off-on switches.
DPST Control Type
Double Pole Single Throw (DPST) is a control type that the switch has two input terminals and two output terminals, each input terminal has 1 corresponding output terminal.This switch serves in circuits as on-off switches.
DPDT Control Type
Double Pole Double Throw (DPDT) is Functions like two separate SPDT switches operated by the same actuator. Only two loads can be On at a time.This switch serves in circuits as on-off-on switches.
