Rear Drive Shaft CV Axle Swing Arm Kit with Brake Assembly for Go Kart ATV Golf Cart

Fitment:
For 4 Wheel Drive DIY ATV, Go Kart, Quad Buggy
Hubs Specification:
Product Type: Wheel Hub
Codition: 100% Brand New
Color: Black
Material: Casting Steel
Spline: 23 Tooth
Diameter Of Centre Hole: Approx. 37mm / 1.46 in
Distance Between Hub Mounting Holes (Centre To Centre): 78mm / 3.07 in
Other Size: As Shown In The Picture
Swing Arm Specification:
Product Type: Rear Swing Arm
Condition: 100% Brand New
Color: Red
Material: Iron
Length of Upper Swing Arm: 210mm / 8.3″
ength of Lower Swing Arm: 280mm / 11″
Axle Specification:
Product Type: CV Axle
Condition: 100% Brand New
Color: Black
Size: As Shown In The Picture
Steering Knuckle Specification:
Product Type: Steering Knuckle
Condition: 100% Brand New
Color: As Shown In The Picture
Material: Casting Steel
4PCS Of Bearings Included: 6006ZZ
Weight: 3592g / 7.92 lb
Gear Housing Specification:
Product Type: Rear Drive Shaft Gear Housing
Condition: 100% Brand New
Color: Black
Size: As Shown In The Picture
Gear Ratio: 11:39
Brake Disc Specification:
Product Type: Brake Disc
Condition: 100% Brand New & High Quality
Color: Silver
Outside Diameter: 180mm / 8.1″
Inner Hole Diameter: 47mm / 1.9″
Bolt Spacing: 29mm / 1.1″
Thickness: 4mm / 0.16″
Mounting Holes: 6 Mounting Holes
Position: Front & Rear
Brake Caliper Specification:
Product Type: Rear Hydraulic Twin Brake Caliper Cylinder
Condition: 100% Brand New
Color: As Shown In The Picture
With Brake Pads: Yes
Tube Length: 140cm / 55.12″
Other Size: As Shown In The Picture
Packing List:
2 * 23T Wheel Hub
2 * Upper Swingarm
2 * Lower Swingarm
1 Pair Of 470mm / 18.5″ CV Axle Kit
1 Pair Of Steering Knuckles
1 * Gear Housing
2 * Tie Rod End
8 * Shock Mount Bracket
2 * 180mm / 8.1″ Brake Disc
1 * Rear Hydraulic Twin Brake Caliper Cylinder
