This is a set of new and fully assembled rear axles with wheel bearings for a Kawasaki Mule UTV.
They fit the following models:
2000-2002 … Mule 2510
2004-2008 … Mule 3000
2001-2008 … Mule 3010
2009-2023 … Mule 4000
2009-2023 … Mule 4010/4010 Trans
*Not intended for use in lifted vehicles
Product features:
Stronger than OEM chromoly hardened steel axle bars
Fitted with neoprene CV boot for added wear and puncture resistance
High speed bearings manufactured for long life
Double lip seals made to keep grease in and dirt out
inobard CV joint spline count: 15 (both)
outboard CV joint spline count: 24 (both)
Replaces Kawasaki OEM # 39158-1105, 39158-1109, 39158-1104, 39158-1119, 39158-1120, 92045-0102
