Polaris Sportsman 850 Touring 2011-2015 2x Rear Upper A-Arm Bushing Pivot Kit

Premium Quality Replacement Part
2x Rear Upper A-Arm Bushing Pivot Kit for Sportsman 850 Touring 2011-2015
For Polaris Models:
Sportsman 850 Touring 2011-2015
Order Includes:
2x Short Pivot Shaft | 5136100
2x Long Pivot Shaft | 5137594 5136468
4x Short Bushings | 5439874
4x Long Bushings | 5436973
2x Short Bolt | 7519043
2x Long Bolt | 7519086
4x Flange Nut | 7547333
4x Flange Washer | 7556153
Short Pivot Shaft Dimensions
Length | 71mm | 2.79″
ID | 10mm | .39″
OD | 16mm | .62″
Long Pivot Shaft Dimensions
Length | 210mm | 8.26″
ID | 10mm | .39″
OD | 16mm | .62″
Short Bushing Dimensions
Length | 30mm | 1.1″
OD Insert | 21mm | .82″
OD Outer | 31mm | 1.2″
Long Bushing Dimensions
Length | 102mm | 4″
Width | 21mm | .82″
Short Bolt Dimensions
Length | 104mm | 4.09″
Threads & Pitch | M10x1.25
Long Bolt Dimensions
Length | 244mm | 9.62″
Threads & Pitch | M10x1.25
