Kawasaki Z900 Z650 Ninja 650 2017-2019 Integrated LED Tail Light Turn Signal

Description:
-Conditon: 100% Brand New.
-High quality,Long-lasting,Super bright
-Simple to fit the tail,brake,and turning sighals(left&right)are all integrated in one
-Lamplight color:Red / Yellow
-Available color for lens: Red/ Clear/Green/Yellow
-Voltage:12V
-Material:Plastic
Feature
*Easy to install;Without instructions.
*If the light work abnormaly,you need to add a resistance.
*Color may have 5% different from the picture shown online.
*Please Ensure This Part Fits Your Motorcycle Before You Place The Order.
Fitment:
KAWASAKI Z 900 2017-2019
KAWASAKI Z 650 2017-2019
KAWASAKI NINJA 650 2017-2019
Wiring Diagram applicable to most bikes:
Black Wire(Negative),
Green Wire(Brake)
Red Wire(Running Light)
1. Connect one end of the resistor to the ground wire on your turn signal harness from your bike.
2. Connect the other end of the resistor to both the YELLOW wire from our taillight and the positive
turn signal wire from your turn signal harness from your bike.
3. Repeat the same process for the other side.
