Husqvarna R13, R16H PTO Drive Belt

More product information 55.3″ V-belt for Husqvarna tractors.
Outer length: La1405mm
Working length: Lw1385mm
Inside length: Li1350mm
Width: 13mm (1/2″)
Height: 8mm
Manufacturer: Kramp FGP013443
Application: Brand
Replacement / Original No. Models/Type
HUSQVARNA 5067684-01, 5310050-14, 5895305-01 PR18 AWD, ProFlex 18, Rider 11 Bio, R13H, Rider 13 AWD, Rider 13 BioClip, Rider 155, Rider 15V2, Rider 15V2 AWD, R16H, Rider 16
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt that is 10mm (3/8″) or 17mm (5/8″) wide.
