Husqvarna CTH126 blade V-belt

More information about the product A89″La A87″Li Husqvarna blade drive V-belt.
Outer length:La2265mm
Working length: Lw2240mm
Inner length: Li2210mm
Width: 12.7mm (1/2″)
Height: 9mm
Manufacturer: Mitsuboshi 13x2210Li A-87
Replacement / Original No. -5324192-71,5321265-20
Application: Brand Models / Type HUSQVARNA CT126, CTH126, LT126, LTH126, SRD17530, TC130, MCCULLOCH MC115T94, M11577, M115-77T, M115-77TC,M115-77RB PARTNER P12-105E, P11577RB
How to measure a belt:
Outer circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure in an arc on the outside (with a tailor’s tape).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Inner circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt with a
Width of 10mm (3/8″) or 17mm (5/8″).
