For Toyota Echo Scion xA xB FWD Pair of Front CV Axle Shafts(For: Toyota)

SKU Z.18725 FQVM-48680-22-3973081 Category Car Parts Tags axle, shaft

SPREAD THE LOVE

Description

Listing Content
1 xFront Left CV Axle Shaft
1 xFront Right CV Axle Shaft
Abs Ring Tooth Count: (Front Left CV Axle Shaft) 48
Abs Ring Tooth Count: (Front Right CV Axle Shaft) 48
Abs Ring Type: (Front Left CV Axle Shaft) Toothed
Abs Ring Type: (Front Right CV Axle Shaft) Toothed
Abs Tone Ring Included: (Front Left CV Axle Shaft) Yes
Abs Tone Ring Included: (Front Right CV Axle Shaft) Yes
Axle Nut Head Type: (Front Left CV Axle Shaft) Hex
Axle Nut Head Type: (Front Right CV Axle Shaft) Hex
Axle Nut Height (in): (Front Left CV Axle Shaft) 6/7
Axle Nut Height (in): (Front Right CV Axle Shaft) 6/7
Axle Nut Height (mm): (Front Left CV Axle Shaft) 21.5
Axle Nut Height (mm): (Front Right CV Axle Shaft) 21.5
Axle Nut Hex Size (in): (Front Left CV Axle Shaft) 1 1/6
Axle Nut Hex Size (in): (Front Right CV Axle Shaft) 1 1/6
Axle Nut Hex Size (mm): (Front Left CV Axle Shaft) 30
Axle Nut Hex Size (mm): (Front Right CV Axle Shaft) 30
Axle Nut Included: (Front Left CV Axle Shaft) Yes
Axle Nut Included: (Front Right CV Axle Shaft) Yes
Axle Nut Length (in): (Front Left CV Axle Shaft) 1 1/3
Axle Nut Length (in): (Front Right CV Axle Shaft) 1 1/3
Axle Nut Length (mm): (Front Left CV Axle Shaft) 34.6
Axle Nut Length (mm): (Front Right CV Axle Shaft) 34.6
Axle Nut Locking Type: (Front Left CV Axle Shaft) Stake
Axle Nut Locking Type: (Front Right CV Axle Shaft) Stake
Axle Nut Thread Size: (Front Left CV Axle Shaft) M22*1.5
Axle Nut Thread Size: (Front Right CV Axle Shaft) M22*1.5
Boot Material: (Front Left CV Axle Shaft) Neoprene
Boot Material: (Front Right CV Axle Shaft) Neoprene
Inboard Joint Type: (Front Left CV Axle Shaft) Male
Inboard Joint Type: (Front Right CV Axle Shaft) Male
Inboard Shaft Connection Style: (Front Left CV Axle Shaft) Male
Inboard Shaft Connection Style: (Front Right CV Axle Shaft) Male
New Or Remanufactured: (Front Left CV Axle Shaft) New
New Or Remanufactured: (Front Right CV Axle Shaft) New
Number Of Inboard Splines: (Front Left CV Axle Shaft) 23
Number Of Inboard Splines: (Front Right CV Axle Shaft) 23
Number Of Outboard Splines: (Front Left CV Axle Shaft) 24
Number Of Outboard Splines: (Front Right CV Axle Shaft) 24
Outboard Joint Type: (Front Left CV Axle Shaft) Conventional
Outboard Joint Type: (Front Right CV Axle Shaft) Conventional
Outboard Shaft Connection Style: (Front Left CV Axle Shaft) Conventional
Outboard Shaft Connection Style: (Front Right CV Axle Shaft) Conventional
Overall Compressed Length (in): (Front Left CV Axle Shaft) 25.16
Overall Compressed Length (in): (Front Right CV Axle Shaft) 34.57
Overall Compressed Length (mm): (Front Left CV Axle Shaft) 639
Overall Compressed Length (mm): (Front Right CV Axle Shaft) 878
