for Curtis 1204410 1204412 / 325A 48V 5K-0?? Motor Controller Replace Curtis 1204-410 225A 48V 5K-0?? & Replace Curtis 1204-412 300A 48V 5K-0?? Golf Carts Club Car Controller

Replaces Part Number : 1204 / 1204-410 / 1204-411 / 101840201 / 1204-412 Made According to Original Products, Quality is Guaranteed,100% Tested Before Shipping. Applicable Models : For use with Club Car DS (Years 1996-Up)
Please Refer to Your Own Part and Make Sure Your Part is 48V / 225A / 5K-0?? Or 48V / 300A / 5K-0??, By default, We will the controller of setting of 48V/ 325A / 5K-0??, It Can Directly Replace 48V / 225A / 5K-0?? and 48V / 300A / 5K-0??.
Curtis (1204) short body controller with four buss bars is pre-set for 5K-0 throttle but It can be adjusted with a hand held Curtis programmer #1313-3301 for use with 8 other throttle inputs. Many other parameters such as acceleration, HPD, voltage, plugging and more are also adjustable.
1 Year Warranty : We Test Each Item and 100% Ensure That Before We Ship, Before and After Sales, We Will Provide Warranty Service For Damaged Products, True Worry-Free Shopping Experience.
We supply motor controller & assemblage, programmer, contactor, accelerator (throttle), meter / gauge, and many other parts, we provide a wild range of products, corresponding each sector of electric vehicle & forklift.
Motor Controller,For Curtis 1204-015
For Curtis 1510-5201/5250
For Curtis 1205-5603
For Curtis 1268-5403
For Curtis 1243-4320
For EZ-GO 73326G02
Voltage (Volts)
36V 48v 48V 48V 36V 36V
Current (amps)
275A 275A 500A 400A 300A 350A
Throttle Type
0-5K??
0-5K?? 0-5K?? 0-5V
Battery Voltage:48V(default setting), 36V
Throttle Type: 5K-0??(default setting), 0-5K?? or 0-5V
Current Rating (amps): 325A ??Compatible with 200A or 300A??
If You Need to Modify Any Controller Parameter, You Need to Have a CURTIS 1313-4331 Handheld Programmer.
If Your Motor Controller is Not 48V/ 5K-0??/200A(or300A),
If You Don’t Sure The Item Compatible With Your Car,
Please Provide The Picture of Your Original Part To Us.
Key Features: For CURTIS Model 1204M-5305 Norminal Battery Voltage (Volts): 48V (default setting) or 36V2 Minute Current Rating (amps): 3255 Second Boost Current Rating (amps): 3581 Hour Current Rating (amps): 140Plug Braking (A2 Busbar): YesPWM operating frequency: 15.6 kHzElectrical isolation to heatsink (min.): 500 VACKSI input current (no contactors engaged):70 mA without programmer 130 mA with programmerTen throttle types can be used with these controllers:Type 0: 2-wire potentiometer, 0?C5k?? Type 1: 2-wire potentiometer, 5k???C0 Type 2: single-ended 0?C5V input Type 3: 2-wire potentiometer, 4.6k???C0 Type 4: 2-wire potentiometer, 5.5k???C0 Type 5: 2-wire potentiometer, 1k???C0 Type 6: ITS input Type 7: single-ended 6.3?C10.6 V input Type 8: single-ended 6?C12 V input Type 9: single-ended 3-wire potentiometer, 0?C5k??
