for Curtis 1204-027 Speed Controller 36V 275amp 0-5K?? Compatible with Golf Carts Club car for Curtis1204 / 1204027

Categories

for Curtis 1204-027 Speed Controller 36V 275amp 0-5K?? Compatible with Golf Carts Club car for Curtis1204 / 1204027

SKU KZQ.00280 Categories , Brand

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on telegram
Share on email
Share on whatsapp
Share on reddit

Description

Replaces Part Number : For Curtis1204/1204-027 , Made According to Original Products, Quality is Guaranteed, Tested Before Shipping.
Applicable Models : This controller fits Golf Carts Club Car
Please Refer to Your Own Part and Make Sure Your Part is 36V / 275A / 0-5K??, By default, We will the controller of setting of 37V/ 275A / 0-5K??.
For Curtis (1204) short body controller with four buss bars is pre-set for 0-5K throttle but It can be adjusted with a hand held Curtis programmer #1313-3301 for use with 8 other throttle inputs. Many other parameters such as acceleration, HPD, voltage, plugging and more are also adjustable.
1 Year Warranty : We Test Each Item and 100% Ensure That Before We Ship, Before and After Sales, We Will Provide Warranty Service For Damaged Products, True Worry-Free Shopping Experience.
We supply motor controller & assemblage, programmer, contactor, accelerator (throttle), meter / gauge, and many other parts, we provide a wild range of products, corresponding each sector of electric vehicle & forklift.
Motor Controller,For Curtis 1204-015
For Curtis 1204-410/412
For Curtis 1205-5603
For Curtis 1510-5201/5250
For Curtis 1243-4320
For EZ-GO 73326G02
Voltage (Volts)
36V 48V 48V 48v 36V 36V
Current (amps)
275A 325A 500A 275A 300A 350A
Throttle Type
0-5K?? 5K-0?? 0-5K??
0-5V
Battery Voltage:36V(default setting), 24V
Throttle Type: 0-5K??(default setting), 5-0K?? or 0-5V
Current Rating (amps): 275A
If You Need to Modify Any Controller Parameter, You Need to Have a CURTIS 1313-4331 Handheld Programmer.
If Your Motor Controller is Not 36V/ 0-5K??/275A,
If You Don’t Sure The Item Compatible With Your Car,
Please Provide The Picture of Your Original Part To Us.
Key Features: For CURTIS Model 1204M-4201, 1204-027 Norminal Battery Voltage (Volts): 36V (default setting) or 24V2 Minute Current Rating (amps): 2755 Minute Current Rating (amps): 2001 Hour Current Rating (amps): 125Plug Braking (A2 Busbar): YesStatus LED output current (max.): < 2 mATen throttle types can be used with these controllers:Type 0: 2-wire potentiometer, 0?C5k?? Type 1: 2-wire potentiometer, 5k???C0 Type 2: single-ended 0?C5V input Type 3: 2-wire potentiometer, 4.6k???C0 Type 4: 2-wire potentiometer, 5.5k???C0 Type 5: 2-wire potentiometer, 1k???C0 Type 6: ITS input Type 7: single-ended 6.3?C10.6 V input Type 8: single-ended 6?C12 V input Type 9: single-ended 3-wire potentiometer, 0?C5k??Operating ambient temperature range: -40??C to 50??CStorage ambient temperature range: -40??C to 85??C
