For Audi TT VW Passat Jetta Golf Beetle Clutch Slave Cylinder 1J0721261J
Categories
- ATV Parts (2098)
- ATV UTV Parts (2198)
- Accessories (187)
- Air&Oil Filters (3)
- Axles (775)
- Bearings (9)
- Body (63)
- Brakes (37)
- Bushings (42)
- Cable (1)
- Chain (9)
- Drive Belt (1)
- Drive Clutch (515)
- Clutch Accessories (445)
- Clutch Kits (40)
- Drive Clutch (30)
- Engine (19)
- Gear box or reverse gear (0)
- Handlebars (2)
- Ignition Coil (2)
- Pinion Shaft (1)
- Rectifier/Regulator (1)
- Seats & Covers (2)
- Solenoid (1)
- Starter (4)
- Switch (1)
- Tools (3)
- Winches & Mounts (10)
- Bicycle Parts (3)
- Car Parts (3739)
- Chainsaw Parts (138)
- Clutch accessories (218)
- Clutch Kits (49)
- Drive Clutch (20)
- Driven Clutch (13)
- Go Kart Parts (198)
- Golf Cart Parts (7501)
- Accessories (1877)
- Air Filter (52)
- Askets & Roof Racks (2)
- Axles (52)
- Battery Charger (89)
- Bearings (53)
- Belt (554)
- Brush Guards, Bumpers, Bars & More (94)
- Bushing (116)
- Cables (72)
- Carburetor (64)
- Cargo Boxes (4)
- Custom Body Kits (4)
- Dash Kits (9)
- Diamond Plate Accessories (18)
- Disc Brake Systems (234)
- Drive Clutch (474)
- Clutch Accessories (68)
- Clutch Kits (154)
- Drive Clutch (111)
- Driven Clutch (97)
- Electric Performance Parts (185)
- Enclosures (55)
- Fans & Blowers (3)
- Fender (47)
- Floor Mats (57)
- Fuel Pump (20)
- Gas Performance Parts (39)
- Gasket (5)
- Gear (17)
- Heaters (3)
- Horns (36)
- Ignition Coil (88)
- Lift Kits (182)
- Light Kits (347)
- Mirrors (37)
- Rear Seats (391)
- Seat Belts (348)
- Seat Covers & Replacement Seats (1)
- Shock Absorber (42)
- Solenoid (52)
- Speed Sensor (20)
- Starter Motor (61)
- Steering Wheels (88)
- Storage Covers (46)
- Tach/Hour Meter (15)
- Tie Rod End (27)
- Tools (35)
- Tops and Roof Supports (16)
- Tuned Exhausts (406)
- Weldments (81)
- Wheel Covers (27)
- Wheels and Tires and rim (698)
- Windshields (41)
- Lawn Mower Parts (574)
- Mini Bike Parts (185)
- Minibike Parts (3)
- Motorboat Parts (9)
- Motorcycle Parts (1339)
- Mower & Tractor parts (666)
- Other Parts (160)
- Others (37)
- Scooter Parts (164)
- Snowmobile Parts (396)
- Tracor Parts (22)
- Tractor Parts (455)
- UTV Drive Clutch (0)
- UTV Parts (1261)
Product tags
Description
Installation Procedure:
Grab your creeper and go under the vehicle.
Get your drip pan and place it under the slave cylinder.
Warning: Do not cross thread the hydraulic line as you install it. Brake fluid will leak out.
Bleed the hydraulic line to slave cylinder
Note: If the air does not all come out you will need to bleed the air from the line attached to the clutch master cylinder. Follow the same procedures as you did with the slave cylinder bleeder screw.
Top off brake fluid.
Operating Principle:
A clutch slave cylinder is a member of the clutch system that provides leverage assistance to the clutch fork.
The clutch slave cylinder operates just like a hydraulic cylinder on a boom lift. The cylinder is connected to the clutch master cylinder located on the firewall next to the brake master cylinder through a hose.
When you push the clutch pedal, brake fluid flows from the clutch master cylinder to the slave cylinder, applying the pressure necessary to engage the clutch.
When you release the clutch pedal, a return spring located on or in the slave cylinder will force the brake fluid back to the clutch master cylinder.
Package:1 Pcs clutch slave cylinder Fitment:
Make Model Year Engine Audi TT 2000-2002 l4 1.8L Volkswagen Beetle 1999-2005 l4 1.8L Volkswagen Beetle 2006-2010 l5 2.5L Volkswagen Golf 1998-2006 l4 2.0L Volkswagen Jetta 1999-2005 l4 2.0L Volkswagen Jetta 1999-2004 V6 2.8L
