CV Axle Shaft for 1984-1988 Corolla TO-8035 (For: Toyota)

SKU Z.18517 4342012060 4342012070 4342020010 60-5025 60-5117 605025 7407 Category Car Parts Tags axle, shaft

SPREAD THE LOVE

Description

Fitment Chart:
Years Make Model Submodel Body Type Drive Type Transmission
1988 Toyota Corolla FX16 FWD Manual
1988 Toyota Corolla FX16 GTS FWD Manual
1987 Toyota Corolla DLX Sedan Automatic
1987 Toyota Corolla FX16 Manual
1987 Toyota Corolla FX16 GTS Manual
1985-1986 Toyota Corolla LE Limited
1984 Toyota Corolla Base
1984-1986 Toyota Corolla DLX
1984-1987 Toyota Corolla LE
Specifications:
Part Category: CV Axle Shaft
Manufacturer Part Number: TO-8035
Vehicle Position: Front Driver Side
Placement on Vehicle: Front Left
Label: CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
Number of Pieces: 1
Abs Tone Ring Included: No
Axle Nut Head Type: Hex
Axle Nut Height (in): 2/3
Axle Nut Height (mm): 17
Axle Nut Hex Size (in): 1 1/6
Axle Nut Hex Size (mm): 30
Axle Nut Included: Yes
Axle Nut Length (in): 1 1/3
Axle Nut Length (mm): 34.6
Axle Nut Locking Type: Cotter pin
Axle Nut Thread Size: M19*1.5
Boot Material: Neoprene
Inboard Joint Type: Flange
Inboard Shaft Connection Style: Flange
New Or Remanufactured: New
Number Of Outboard Splines: 26
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Conventional
Overall Compressed Length (in): 19.61
Overall Compressed Length (mm): 498
Interchange Part Number: 2143 40-18721 40751037 410822 4342012020 4342012021 4342012040
Replaces Part Numbers: 4342012060 4342012070 4342020010 60-5025 60-5117 605025 7407
Replacement Part Numbers: 80-3718 80-6126 AX-2512 CV2512 CV8601 TO-8-8511 TO-8035 TO-8717
Replace Part Numbers: TO-8721
Brand Label: CV Axle Shaft
