CV Axle Shaft for 1983-1988 Tercel TO-8037 (For: Toyota)

SKU Z.18548 4342016200 4342016201 4342016202 Category Car Parts Tags axle, shaft

SPREAD THE LOVE

Description

Fitment Chart:
Years Make Model Body Type
1987-1988 Toyota Tercel Wagon
1983-1986 Toyota Tercel
Specifications:
Part Category: CV Axle Shaft
Manufacturer Part Number: TO-8037
Vehicle Position: Front Driver Side
Placement on Vehicle: Front Left
Label: CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
Number of Pieces: 1
Abs Tone Ring Included: No
Axle Nut Head Type: Hex
Axle Nut Height (in): 6/7
Axle Nut Height (mm): 22
Axle Nut Hex Size (in): 1 1/6
Axle Nut Hex Size (mm): 30
Axle Nut Included: Yes
Axle Nut Length (in): 1 1/3
Axle Nut Length (mm): 34.6
Axle Nut Locking Type: Cotter pin
Axle Nut Thread Size: M20*1.5
Boot Material: Neoprene
Inboard Joint Type: Male
Inboard Shaft Connection Style: Male
New Or Remanufactured: New
Number Of Inboard Splines: 20
Number Of Outboard Splines: 23
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Conventional
Overall Compressed Length (in): 30.67
Overall Compressed Length (mm): 779
Interchange Part Number: 2103 40-18703 410818 4342016040 4342016042 4342016060 4342016122
Replaces Part Numbers: 4342016200 4342016201 4342016202 4342016220 60-5002 66-5002 7403
Replacement Part Numbers: 704527 80-3709 80-6137 AX-4527 CV4527 CV8606 TO-8-8502 TO-8037
Replace Part Numbers: TO-8703
Brand Label: CV Axle Shaft
