Boat Rocker Switch Canal R Series R210-C5L-BO Orange Illuminated ON/Off 20A 16A Double Pole DPST 4 Pins 2 Position Toggle Replaces for Hongju R Series Defond DRH 2415 3 SCI R13-69 Durable

SKU KG.06598 Categories Electric Performance Parts, Golf Cart Parts Brand switch

SPREAD THE LOVE

Description

[Model & Rating] Model: R210-C5L-BO. Rating Voltage: 20A 125VAC/250, 3/4HP, 16A 125/250VAC, 1/4HP, 10(2)A~250VAC T125/55, 16(4)A~250VAC T125/55 (VDE, ENEC10, CQC).
[Works In] Rocker Toggle Switch Works In Electromagnetic Furnace, Water Dispenser, Buses, Boats, Marine, Trailers, Treadmill, Coffee Pot, Kitchen Appliance Etc. Replaces: Hongju R Series, Defond DRH 2415 3 and SCI R13-69.
[Function & Electrical Life] Function: ON-OFF (Built in with neon lamp). Electrical Life: 6000(UL); 10000(VDE) Cycles.
[Size] The 4 Pin Rocker Switch Snaps Into Roughly An 22x30mm Panel Hole Cutout Size. Overall Size: 32 x 25 x 38mm (L*W*H).
[Easy Installation] 100% Brand New High Quality Switch Easy Installation Snaps Conveniently Into Appliance, Contains Red Translucent Rocker Lamp, Quick Connect Terminals. You Will Receive 1pcs Switch.
Product Description
Specification:* Model: R210-C5L-BO
* 20A 125VAC/250, 3/4HP
* 16A 125/250VAC, 1/4HP
* 10(2)A~250VAC T125/55
* 16(4)A~250VAC T125/55 (VDE, ENEC10, CQC)
* Switching Method: ON-OFF
* Initial Contact Resistance: 20m ohm max.
* Insulation Resistance: 100M ohm min, at 500VDC
* Dielectric Strength: 1,000 VAC(UL), 3000VAC(VDE)for 1 minute
* Electrical Life: 6000(UL); 10000(VDE) cycles
* UL Recognized Component, VDE & ENEC10 in Europe, CQC in Asia
* Standard 22x30mm Snap-In Cutout Size
* DPST
* Quick-connect terminals
* Built in with neon lamp
* Panel cut-out roughly 22mm x 30mm (snaps in)
* Bezel 32mm x 25mm
* One actuatorFeatures:– This is the original OEM Canal R Series switch commonly found in appliances like oven hood range fans.– The switch meets the highest electrical standards, and it is an ideal replacement for home appliance repair tools.– Snaps conveniently into appliance, contains red translucent rocker lamp, quick connect terminals, and constructed of plastic housing material.Package Include:* 1PC Switch
