Belt PTO Clutch Kit for Husqvarna RZ5424 Z254 RZ5426 RZ54i Z254i Poulan 541ZX 539114557 532179334 179334

Replaces OEM Part Number: PTO Clutch: Ariens 4387900, Gravely 4387900, Husqvarna 587241601, 179334, 400008, 414336, 471717P, 532179334, 532400008, 532414336, Craftsman 179334, 400008, 414336, 471717P
Replaces OEM Part Number: Belt: Husqvarna 539114557
Compatible with: Poulan 541ZX (966681901); Husqvarna RZ5424 (289823, 966659302, 967003701), RZ5426 (967003605, 967003606, 967003601, 967003602), RZ54i (967003603), Z254 (967324101, 967324301,
PTO Torque: 120 FT.LBS; Pulley OD: 6.10″; Shaft Diameter: 1″
Belt: Width: 5/8″; Length 154″Shop LawnRAZOR Blades
Visit the Store
Shop Mower Parts
Visit the Store
Shop Bars and Chains,MK1006384
About Parts specializes in the highest quality lawn & garden replacement parts. Our parts meet or exceed the quality of the original parts that come with your machine. Some of the Parts product categories include blades, spindles, pulleys, idlers, and chainsaw chains. Let Parts fix your machine today!
Belt and GEN 3 PTO Clutch Kit MK1006384
Gen 3 Power Take Off Clutch
Includes: Belt and GEN3 PTO ClutchCompatible with the following brands: Ariens,Gravely,Husqvarna,Craftsman,Ogura,PoulanReplaces for the following OEM MPN’s: 532414336,532179334,GT1A-EH07,15772,414336,587241601,179334,400008,532400008,53464900,414717,53594500,539114595,532414717,4387900,708563,917179334,917414717,471717P,B1XT0569,GT15AEH07,GT1-5A-EH07,GT1AEH07,708346
Voltage Insulation: 1000V
Performance Enhancement: No Friction Ring
Temperature Fuse Melting Point of Coil: No Fuse Inside
Torque: 120 FT.LBS
Pulley Outer Diameter: 6.10 Inches
Belt Type: Deck Belt
Belt Length: 154 inches
Belt Width: 5/8 inch
Lawn Mower Belt
GEN 3 PTO Clutch
Life: B10 life of 25,000 cycles at 2000 hoursEnvironment: Ambient -40??F to +200??FPerformance Enhancement: Friction Ring
Bearing Operating Temperatures (-40??F to +350??F)Coil Operating Temperatures (-40??F to +350??F)Temperature Fuse Melting Point of Coil 365??F
Operating Speed: Input speeds up to 3600 rpmStop Time: 4 seconds Voltage Insulation: 1000V
The GEN 3 Difference
Stainless steel leaf springsBetter dynamic balance with reduced pulley weight370??F auto thermal cutoff preventing clutch damageIncreased blade acceleration with higher initial torqueEnhanced stopping time with superior spring brake systemAnti high & low temperature bearing and encapsulated coils (-40??F to 370??F) for consistent performance
