A69 Mitsuboshi 13x1750Li V-belt

More product information V-belt 69Li / 71La” Mitsuboshi 13x1750Li
Outer length: La1800mm
Working length: Lw1782mm
Inside length: Li1750mm
Width: 12.7mm (1/2″)
Height: 8.5mm
Manufacturer: Mitsuboshi 13x1750Li
Replacement / Original No. -5440681-01
Application: Husqvarna Rider lawn tractor blade drive with Combi 94 mower deck Brand Models / Type HUSQVARNA Rider 13C (R13C), Rider 15C (R15C), R213C,R216
Replacement / Original No. – 9585-0199-01, 9585-0172-01
Application: unit drive
Brand Models / Type
CASTEL GARDEN XK, XK4 (4WD) STIGA Park 105 Combi (4WD)
Replacement / Original No.: 754-04189
Application: Cub Cadet travel drive
Brand Models /Type
CUB CADET FMZ42 (2008-09), FMZ48 (2009-14), FMZ50 (2008-14) GUTBROD GLX122FH (2011) MASSEY FERGUSON MF48-22FMZ (2011-2014), MF50-22FMZ (2009-12)
How to measure a belt:
Outer Circumference – LA is measured on the outside of the belt. In the case of longer belts, it is important to measure with an arc on the outside (with a tailor’s tape measure).
Working circumference – LW is measured in a straight line, after cutting, by stretching the tape measure along the belt (with a measuring tape).
Internal circumference – LI is measured inside the belt (with a special tape measure for belts).
You should also remember about the
Width of the belt, if the original belt is 13mm (1/2″) wide, you should not use a belt with a
Width of 10mm (3/8″) or 17mm
