72" Deck Spindle for John Deere 777 797 Max-Frame ZTrak / Z997R Diesel ZTrak

Premium Quality Replacement Part
Mower Deck Spindle Assembly
Compatible with John Deere Models:
2032R
(MY17 – MY19)(PIN: 1LV2032RTGH100008 – 1LV2032RELK119197)
(MY23- )(PIN: 1LV2032RCNP125418- )(PIN: 1LV2032RPNP200761- )
2036R
(MY17- )(PIN: 1LV2036RHGH200101 – )(PIN: 1LV2036RVHH300101 – )
2038R
(MY17 – MY19)(PIN: 1LV2038RPGH100101 – 1LV2038RELK108823)
(MY20 – MY22) (PIN: 1LV2038RJLL108824 – 1LV2038RLNN114880)
(PIN: 1LV2038RVLL200101 – 1LV2038RTNN201345)(PIN: 1LV2038RJLL300101 – 1LV2038RTNN300585)
(MY23- )(PIN: 1LV2038RLNP114981- )(PIN: 1LV2038RTNP201396- )(PIN: 1LV2038RPNP300611- )
3033R
( -MY17) (PIN: – 1LV3033RTHH102720)(PIN: – 1LV3033RCHH200175)(PIN: – 1LV3033RLHH300210)
(PIN: – 1LV3033RKHH401000)(PIN: – 1LV3033RJHH500210)(PIN: – 1LV3033RKHH600225) 72D”
(MY18-MY19)(PIN:1LV3033REHJ103100-ELK106291)(PIN:1LV3033RHHJ200201-TKK200639)
(PIN:LV3033R300301-300641)(PIN:1LV3033RCHJ401101-CKK402919)
(PIN:LV3033R500301-500839)(PIN:LV3033R600225-600639)
3038R
(1LV3038REHJ200001- )
3039R
( -MY17) (PIN: – 1LV3039RKHH102100)(PIN: – 1LV3039RLHH402095)(PIN: – 1LV3039RJHH500210)
(PIN: – 1LV3039RKHH600225)(MY18-MY19)(PIN:1LV3039RCHJ102201-1LV3039RELK105228)
(PIN:1LV3039RKHJ402101-1LV3039RCKK404699)
(MY20-MY22)(PIN:1LV3039RJLL105229-KPN108608)(PIN:1LV3039RJLL200101-HPN200570)
(PIN:LV3039R300101-300189)(PIN:1LV3039RTLL404702-CPN408614)
(PIN:LV3039R500108-500885)(PIN:LV3039R600101-600139)
(MY24- )(PIN: 1LV3039RJPR108652 – )(PIN: 1LV3039RCPR408640 – )
3045R
(1LV3045RKHJ200001- )
3046R
(MY18-MY19)(PIN:1LV3046RHHJ101301-1LV3046RTKK405184)
(PIN:1LV3046RHHJ402201-1LV3046RCKK404699)
( -MY17)(PIN: – 1LV3046RAHH101240)(PIN: – 1LV3046RCHH402130)
(PIN: – 1LV3046RJHH500210)(PIN: – 1LV3046RKHH600225)
1504, 1505 Professional Lawnmower 72″
1550, 1570, 1575, 1580, 1585 TerrainCut 60″, 62″, 72″
1600 Turbo Series II Wide Area Mower
3120, 3320, 3520, 3720 Compact Utility Tractor
1400, 1500 Series Front Mowers 60″ 72″
777, 797 Max-Frame ZTrak 72″
997 Mid-Mount ZTrak 72″
2305 and 2X20/3X20/4X20 Series 70D
Z997R Diesel ZTrak 72″
Order Includes:
1 x Spindle Assembly:
TCA24881, TCA25356, TCA51058, TCU39458, 285-888
Height: 7.0 in – 177.8 mm
Width: 7.0 in – 177.8 mm
Inner Diameter: 0.63 in – 16 mm
Mounting Hole Diameter: 4.0 in – 101.6 mm
