42 Universal Seat Belts 4 Retractable Belts Replacement for Most Golf Cart

Categories

42 Universal Seat Belts 4 Retractable Belts Replacement for Most Golf Cart

SKU AQD.00915 1-8295970-290427 Categories , Tags , , ,

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on telegram
Share on email
Share on whatsapp
Share on reddit

Description

Golf Cart Seat Belts is retractable , suitable for most of two-seater golf cart with modified rear seats.
If the original factory is a 4-seater golf cart, it is not applicable.
Needs to drill holes in the backrest bracket, otherwise it is not replacement for TXT.
Not replacement for 2 Passenger Club Car Precedent, Yamaha G29 Drive and EZGO RXV.
Any question please feel free to contact us.
Product Description
42″ Universal Golf Cart Seat Belts 4 Retractable Belts Replacement for Most Golf Carts
How to install by yourself
Step 1:
Attach the main bracket with the two shackle plates and zinc screws, then tighten the screws with two 3/8-inch (10mm) spanners.
Step 2:
Attach the bracket on the rear cart body strut with shackle plates and screws .
Install the screws and tighten the screws with a 5/8-inch (17mm) spanner and a 5/8-inch (17mm) socket.
Note: Remember keep the bracket 5cm height from the rear cart body. Some carts drilling may be required.
Step 3:
Install the front buckles and make the ends keep some angle to the rear seat. The two buckles should be mirror images of each in the middle of the seat. Tighten the screw with a 3/4-inch (19mm) spanner and a 3/4-inch (19mm) socket.
Note: Remember to have the belt release button facing out so it can be easily released. The two female ends should be mirror images of each in the middle of the seat. Tighten firmly.
Step 4:
Install the rear belts. They install exactly like the front belts – male on the outside of the cart, female in the center of the seat. Install the rear buckles and make the ends keep some angle to the rear seat. The two buckles should be mirror images of each in the middle of the seat. Tighten the screw with a 3/4-inch (19mm) spanner and a 3/4-inch (19mm) socket
Package Included:
1x universal bracket
4x retractable Belts
all needed hardware
