4 Row Radiator+Shroud Fan 1451 For 1985-1997 Ford Bronco F150 F250 F350 5.0L V8

SKU SRQ.00641 1451DPI1451,SBR1451,CC1451,EC1451,AE1451,MC1451.KKS1451 Category Car Parts Tags cooling radiator, heat sink

SPREAD THE LOVE

Description

Features:1. Made from Aircraft grade aluminum for prolonged lifespanand with raw aluminum finish2. Brazed core technology to guarantee optimum performance and dependability3. All Aluminum 2mm thick tanks and fittings,Ensure it’s hard and durable4. Billet Aluminum CNC machined fill neck rugged and durable5. ergonomic design CNC machined cap with Engraved craftsmanship, anodized treatment.6. OE style brass petcock drain much better than other plastic one on eBay Fan Specification:Diameter : 12” (Blade to Blade)Voltage: DC 12 VoltsWattage: 80WFan Thickness: 2.5″Number of Blades: 10 S-Type bladesMaximum Fan CFM??Cubic Feet per Minute??: 2150cfmMaximum Fan RPM??Revolution(s) Per Minute??: 2000??10%S-Type Blade pull push design, to make air flow more efficient and bring more cooling EffectPowerful 80 watt motor will keep your engine cool. Thermostat Kit:
Universal fit for any automotive vehicle and electric fan.
Activates by grounding electric fans at preset temperature.
185’F turn-on temperature, 165’F turn-off temperature.
3/8″ NPT thread-in brass probe included.
Probe typically threads into radiator, water outlet or manifold.
Thermostat Relay Kit Instructions??
RED + connect directly to battery.
WHITE wire to ignition switch power source.
BLACK goes to thermos switch.BLUE wire goes to the Fans. Radiator Size:Row Count: 4 RowsCore Size: 18-3/8″ H x 27-1/2″ L
Overall Size: 22-1/2″ H x 37-1/4″ L
Upper Inlet: 1-3/4″
Lower Outlet: 1-3/4″Transmission Cooler: ??38??305??1/4-18NPT??T?? Application:
For Ford F-Series F150 F250 F350 Bronco V8 Engine 1983-1997
For 1985-1996 Ford Bronco Radiator 5.0L & 5.8L V8 Engine
For 1985-1996 Ford F150 Truck Radiator 5.0L & 5.8L V8 Engine
For 1985-1997 Ford F250 Truck Radiator 5.0L & 5.8L & 7.5L V8 Engine
For 1985-1997 Ford F350 Truck Radiator 5.0L & 5.8L & 7.5L V8 EngineManufacturer Part Number : 1451,DPI1451,SBR1451,CC1451,EC1451,AE1451,MC1451.KKS1451 Package Include:
1 X 4-Row Aluminum Radiator
1 X CNC Machined Radiator Cap
1 X Aluminum Shroud
2 X 12″ Fans (Includes mounting kits)1 X Thermostat Relay Kit
