36 Volt ezgo Solenoid, EZGO Electric Golf Car Relay #70 Series Relay Replaces E-Z-Go Electric Golf Cart 27855G01, 11761G1, 27855G02, 31680G1, 3016

SKU DCF.03846 US-AUTO4T-36V Categories Golf Cart Parts, Solenoid Tags electromagnetic valve, solenoid, solenoid valve

SPREAD THE LOVE

Description

Voltage 36 Volt,4 terminal Heavy-duty Solenoid with Copper Contacts,Flat Mounting Bracket/ Apply For Marathon Ezgo TXT Series ,1980-2010 Electric Golf Cart,
Replaces Part #’s: 70-120224, 3016, 11761-G1, 27855-G01, 27855-G02, 31680-G1,Cole Hersee 24080, E-Z-Go 11761GA
Resistance is 18 ,Max Transient current can be 200A, but Continuous Working Current recommend 80amp/ Dimensions : 2) 5/16-24 Contact Terms/ 2) 10-32 Terminal/ Mounting holes: 5/16 x 19/32, 2-13/64 on centers
Acts as the conduit between the golf car battery and starter generator, Copper alloy contact terminals Insulated base w/ steel housing / MAKE SURE YOUR SMALL DIODE IS IN THE CORRECT DIRECTION WITH THE LINE POINTING TO THE POSITIVE SIDE.
WARNING: This is a start solenoid only finish work when your key start, if be Continuous Duty,can work 5 minutes under 150Amp, but NEED BREAK otherwise will be too hot to burned or fired
Specifications
Voltage
12VDC
Resistance
14
Capacity
10.2W
Max Transient Flash Current
300Amp
Continuous Working Current
Under 150Amp
Replaces
70-111224 3635820 1114208 1114218 1114223 1114534 1114547
Contact Studs
5/16 -24 Studs Standard & Long
Bracket mounting
Holes 5/16 x 19/32 2-13/64 on Center
How to Install The solenoid Relay
