29" 32" 44" Go Kart Rear Live Axle Kit Sprocket Hub Brake Assembly chain Disc

Specification: If you buy——29″ Rear Axle Kit+T8F chain +brake assembly
Chain Sprocket:T8F 58T

Fit for many 50cc 70cc 90cc atv quads, such as Atomik , Motowork, DHZ , LEI etc.

This is a complete rear axle kits for gokart.

Perfect for DIY gokart projects or rebuilds.

It will come like the photo shows.
Package includes :Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of wheel hubs+T8F Chain+Brake assembly If you buy——29″ Rear Live Axle Kit + Brake Assembly
This is a live axle kit for DIY rebuild Go Kart, ATV, Quad and Drift Trikes

Axle Overall length (from end to end): 740mm (29 1/8″)

The thickest part of the axle is 22mm (7/8″)

Chain Sprocket: T8F 58 Teeth

Brake Disc Diameter: 160mm(6 1/4″)

Bearing model: 6904RS

Spline teeth: 17T and 19T
Package includes :Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of 4 bolt wheel hubs+Brake Assembly If you buy—— 32″Rear Axle Kit +428 chain+Brake assembly
This is a live axle kit for DIY rebuild Go Kart, ATV, Quad and Drift Trikes

Axle Overall length (from end to end): 815mm (32″)

The thickest part of the axle is 30mm (1.2″)

Chain Sprocket: 428 37 Teeth

Brake Disc Diameter: 190mm(7.5″)

Spline teeth: 24T and 28T
Package includes :Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of 4 bolt wheel hubs+428 chain+Brake assembly If you buy—— 32″Rear Axle Kit +Brake assembly
This is a live axle kit for DIY rebuild Go Kart, ATV, Quad and Drift Trikes

Axle Overall length (from end to end): 815mm (32″)

The thickest part of the axle is 30mm (1.2″)

Chain Sprocket: 428 37 Teeth

Brake Disc Diameter: 190mm(7.5″)

Spline teeth: 24T and 28T
Package includes :Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of 4 bolt wheel hubs+Brake assembly If you buy——44″ Live Axle Kit +530 Chain+Brake assemblyDescription:
Type: Rear Axle Kit

Axle Overall length (from end to end): 1128mm (44.4″)

The thickest part of the axle is 33mm (1.3″)

Chain Sprocket: 530 37 Teeth

Brake Disc Diameter: 220mm(8.66″)

Other Dimensions: As pictures shown

Note: Installation Instructions is not included. Professional installation is recommended.
Package Included:Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of 4 bolt wheel hubs+Chain+Brake assembly If you buy——44″ Rear Axle Kit Description:
Type: Rear Axle Kit

Axle Overall length (from end to end): 1128mm (44.4″)

The thickest part of the axle is 33mm (1.3″)

Chain and Sprocket: 530 37 Tooth

Brake Disc Diameter: 220mm(8.66″)

Other Dimensions: As pictures shown

Note: Installation Instructions is not included. Professional installation is recommended.
Package includes: Rear Axle + Pair of pillow blocks + Sprocket + Brake Disc + Pair of 4 bolt wheel hubs
