14.75″ 375mm Rear Air Suspension Shocks Absorber For Yamaha Banshee ATV Scooter

Categories

14.75" 375mm Rear Air Suspension Shocks Absorber For Yamaha Banshee ATV Scooter

SKU JZQ.15871 Category Tags ,

SPREAD THE LOVE

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on telegram
Share on email
Share on whatsapp
Share on reddit

Description

Condition: Brand new/Never used
Color: As picture show
Material: Solid Steel+Aluminium Alloy
Installation Type: Eye to Eye
Fitment: Universal Fit. Work perfectly on most 150cc~750cc street bikes, Scooters and Moped Quad (ATV) with shocks of 375mm eye to eye distance. Great choice for replacement, style upgrading and all kinds of bike modification. **Please check below dimension before bidding.
Dimension:
Total Length: 400mm (15.75″)
Length of Eye to Eye Core: 375mm (14.75″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 8mm
Spring Width: 60mm
Working Stroke: 68mm
Spring Stiffness: 110 kg
Maximum load: 300 kg (??660 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
Fitting manual is not included. installed by qualified mechanic is recommended.
Packaged Included: 1 Pair Shock Absorbers
