1243-4320 36V 300Amp 0-5V for Electric Vehicle Curtis Seperately Excited Motor Controller for SepEx HangCha Noblift ZoWell Electric Pallet Trucks Controller 12434320 360104320

Replaces Part Number : 1243-4320, 12434320, 360104320 Made According to Original Products, Quality is Guaranteed,100% Tested Before Shipping.
Applicable Models : For Electric Vehicle Curtis Seperately, For SepEx HangCha Noblift ZoWell Electric Pallet Trucks.
Replaces 24V-36V Seperately Excited Motor Controller, By default, we will the controller of setting of 36V / 300A / 0-5v.
Please Refer to Your Own Part and Make Sure Your Part is 36V, 300A, 0-5V.
1 Year Warranty : We Test Each Item and 100% Ensure That Before We Ship, Before and After Sales, We Will Provide Warranty Service For Damaged Products, True Worry-Free Shopping Experience.
We supply motor controller & assemblage, programmer, contactor, accelerator (throttle), meter / gauge, and many other parts, we provide a wild range of products, corresponding each sector of electric vehicle & forklift.
Motor Controller,For Curtis 1510-5201/5250
For Curtis 1205-5603
For Curtis 1204-410/412
For Curtis 1268-5403
For EZ-GO 73326G02
For Curtis 1204-015
Voltage (Volts)
48v 48V 48V 48V 36V 36V
Current (amps)
275A 500A 325A 400A 350A 275A
Throttle Type
0-5K 5K-0 0-5K
0-5K
Battery Voltage:36V(default setting),24V
Throttle Type: 0-5V(default setting), 5K-0 or 0-5K
If You Need to Modify Any Controller Parameter, You Need to Have a CURTIS 1313-4331 Handheld Programmer.
If Your Motor Controller is Not 36V/300A/ 0-5V.
If You Don’t Sure The Item Compatible With Your Car,
Please Provide The Picture of Your Original Part To Us.
Key Features: For CURTIS Model P143-4322, 1243-4320, 1243-4322 Norminal Battery Voltage (Volts): 36V (default setting) or 24VPWM operating frequency: 16 kHzElectrical isolation to heatsink (min.): 500 VACKSI input voltage (minimum): 16.8 VOvervoltage protection:24V models: cutback at approx. 30V, cutback at 34V 36V models: cutback at approx. 45V, cutback at 49VDrive Current Limit (amps): 300 Amature:2 Minute Current Rating (amps): 300 1 Hour Current Rating (amps): 100Throttle Type: 0-5V(default setting), 5K-0 or 0-5K Ambient operating temperature range: -40 C to 50 CNet Weight: 1.45 kg
