1-3/8" 6-Spline PTO Shaft 20"-24" T1 Round End for Tractors
1-3/8" 6-Spline PTO Shaft 20"-24" T1 Round End for Tractors
1-3/8″ 6-Spline PTO Shaft 20″-24″ T1 Round End for Tractors
Part Number:
T1-YIIIP-500-05B-05B, T1-500-05B-05B-YIIIP
Description:
??1-3/8″ Standard Size??
Tractor End: 1-3/8″ x 6 Spline; Implement End: 1-3/8″ x 6 Spline. Constructed in the 6-spline end on both ends, our brush hog PTO shaft has a standard size of 1 3/8″, which can match perfectly with the same size and type of implements and tractors, featuring superior driving force for your machinery.
??Telescopic Tube Design??
Compressed Length: 19.7″ / 500 mm; Extended Overall Length: 23.6″ / 600 mm. The tiller PTO shaft is designed with a telescoping steel tube, a universal joint and yokes. It has 16Hp, 12Kw, and 210Nm torque at 540rpm, while at 1000rpm features 24Hp, 18Kw, and torque 170Nm. It allows two sides of the PTO drive line shaft to spin at different speeds.
Specifications
Model: T1-Y T1-YIIIP*500mm*1.05.05B*1.05.05B
Part Type: PTO Drive Shaft
Series: 1
Material: 20CrMnTi & Q345 Steel
Tractor End: 1-3/8″ x 6 Spline
Implement End: 1-3/8″ x 6 Spline
Compressed Length: 19.7″ / 500 mm
Extended Overall Length: 23.6″ / 600 mm
At 540RPM: 16Hp, 12Kw, 210Nm
At 1000RPM: 24Hp, 18Kw, 170Nm
Color: Yellow
